Full Description

This Standard establishes the requirements for creating orthographic views for item description. The topics covered include the multiview system of drawing, selection, and arrangement of orthographic views, auxiliary views, sectional views, details, and conventional drawing practices. Space geometry and space analysis and applications are included in the appendices for informational purposes.
